psdrivers.h File Reference

#include <adolc/adolcexport.h>
#include <adolc/drivers/absnormalform.h>
#include <adolc/interfaces.h>
#include <adolc/internal/common.h>
#include <span>

Include dependency graph for psdrivers.h:

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Namespaces
namespace	ADOLC

Enumerations
enum class	ADOLC::UpdateConsts { ADOLC::True , ADOLC::False }
	Compile-time selector for constant-term updates in ADOLC::abs_normal. More...

Functions
template<UpdateConsts uc = UpdateConsts::True>
ADOLC_API int	ADOLC::abs_normal (short tapeId, std::span< const double > x, AbsNormalForm &anf)
	Compute the abs-normal form of a taped function at a point.
template<>
ADOLC_API int	ADOLC::abs_normal< UpdateConsts::True > (short tapeId, std::span< const double > x, AbsNormalForm &anf)
	Specialization that updates cy and cz after evaluation.
template<>
ADOLC_API int	ADOLC::abs_normal< UpdateConsts::False > (short tapeId, std::span< const double > x, AbsNormalForm &anf)
	Specialization that leaves cy and cz unchanged.
BEGIN_C_DECLS ADOLC_API fint	directional_active_gradient_ (fint, fint, double *, double *, double *, double **, short *)
ADOLC_API int	directional_active_gradient (short tag, int n, const double *x, const double *d, double *g, short *sigma_g)
ADOLC_API fint	abs_normal_ (fint *ftag, fint *fdepen, fint *findep, fint *fswchk, fdouble *fx, fdouble *fy, fdouble *fz, fdouble *fcz, fdouble *fcy, fdouble *fJ, fdouble *fY, fdouble *fZ, fdouble *fL)
ADOLC_API int	abs_normal (short tag, int m, int n, int swchk, const double *x, double *y, double *z, double **Y, double **J, double **Z, double **L)
	Compute the ABS-normal form of a taped function.

Function Documentation

abs_normal()

ADOLC_API int abs_normal	(	short	tag,
		int	m,
		int	n,
		int	swchk,
		const double *	x,
		double *	y,
		double *	z,
		double **	Y,
		double **	J,
		double **	Z,
		double **	L
	)

Compute the ABS-normal form of a taped function.

This routine evaluates the abs-normal form in the same ordering used by the driver interfaces: function outputs first and switching variables second, i.e.

\[ \left[\begin{array}{c} y\\ z \end{array}\right] = \left[\begin{array}{c} b\\ c \end{array}\right] + \left[\begin{array}{cc} Y & J\\ Z & L \end{array}\right] \left[\begin{array}{c} x\\ |z| \end{array}\right] \]

(see Griewank et al.: Solving piecewise linear equations in abs-normal form) associated with a previously recorded tape. It computes function values, switching variables, and the components needed for piecewise-linear / piecewise-smooth analysis.

Warning

The ordering of switching variables and their corresponding rows in J, Z, and L is not guaranteed to be stable across different compilers, optimization levels, or minor changes in the taped operations.

For example, for

\[ f(x) = |x_0 - x_1| + |x_2 - x_3| \]

a compiler may process the absolute values in either order. As a consequence, the first switching variable may correspond to \(|x_0 - x_1|\) (so its row depends on \(x_0, x_1\)), or instead to \(|x_2 - x_3|\) (so its row depends on \(x_2, x_3\)). This yields a different row structure in the abs-normal form even though the mathematical function is identical.

Parameters

tag	Tape identifier.
m	Number of dependent variables.
n	Number of independent variables.
swchk	Number of switching variables (as returned by get_num_switches()).
x	Base point (input values), array of length n.
y	Function values at x, array of length m.
z	Switching variable values, array of length swchk.
Y	Matrix of size m × n.
J	Matrix of size m × swchk.
Z	Matrix of size swchk × n.
L	Lower-triangular matrix of size swchk × swchk.

Returns

Zero on success, nonzero on failure.

abs_normal_()

ADOLC_API fint abs_normal_	(	fint *	ftag,
		fint *	fdepen,
		fint *	findep,
		fint *	fswchk,
		fdouble *	fx,
		fdouble *	fy,
		fdouble *	fz,
		fdouble *	fcz,
		fdouble *	fcy,
		fdouble *	fJ,
		fdouble *	fY,
		fdouble *	fZ,
		fdouble *	fL
	)

directional_active_gradient()

ADOLC_API int directional_active_gradient	(	short	tag,
		int	n,
		const double *	x,
		const double *	d,
		double *	g,
		short *	sigma_g
	)

directional_active_gradient_()

BEGIN_C_DECLS ADOLC_API fint directional_active_gradient_	(	fint	,
		fint	,
		double *	,
		double *	,
		double *	,
		double **	,
		short *
	)
